Product Description
Min. Input Air Pressure: 85 PSI / 6 Bar.
Air Supply Req: Filtered, dry compressed air source. 2 CFM / 3.4 m3/min
Automatic Cleaning Cycle Time: Approx. 60 seconds.
Number of Cleaning Tanks: 2 separate cleaning tanks (Dual-compartment configuration).
Solvent Pail Capacity (User-Supplied)
Two 5-gallon (19 L) pails (One full for rinsing, one with 3 gallons for washing).
Fume Extraction System
Included (Dual extraction) (Dedicated fume extractor for each cleaning tank).
Dual control sets (one per tank): Timer control, gun/vent switches, flow control knobs for vent, gun, air purge, and rinse cycle.
Air rinse control.
Separate Cover switch valves for each compartment.
63 kg (139 lbs)
910mm (36”) Width
1440mm (57”) Height
475mm (19”) Depth
Custom Field
Ready_Freight_Dg_Type No
Primary_Sale_Unit Each
Reorder_Multiple 1
